G5 PRO Industrial FGF Pellets 3D Printer, Granular 3D Printer
G5 PRO Industrial FGF Pellets 3D Printer, Granular 3D Printer

G5 PRO Industrial FGF Pellets 3D Printer, Granular 3D Printer
G5 PRO Industrial FGF Pellets 3D Printer, Granular 3D Printer
PioCreat INDUSTRIAL-GRADE PELLET 3D PRINTER G5 PRO 500×500×500mm Brand new print head assembly Magnetic attraction platform Supports both automatic leveling and auxiliary leveling modes The Z-axis adopts the driver to drive the power more strongly Low-cost, high-efficiency 3D printing technology meets users' demands for high-speed, high-precision and multi-material 3D printing. At present, G5 PRO has been deeply applied and practiced in the fields of teaching and research, molds, and sculpture.
Product ParameterTechnical:FGF Fused Granules Fabrication
Printing Size:500*500*500mm
Machine Size:765*890*990mm
Feeding structure:Screw Rod Extrusion
Nozzle:Single Nozle
Nozzle Diameter:0.4-4.0mm(optional3.0)
Printing Layer:0.2-1.0mm
Hotbed Tempature:≤130℃
Nozzle Tempature:≤400℃
Power Voltage:AC100-240V
Rated Power:1.25KW
Particles Diameter:2-5mm
Printing Material:PLA/PETG/PETG+10%GF/ABS/PA6/PS/GPPS/PP/PP+30%GF/TPE/TPV/TPU/15-5PH and other composite materials
slicer software:Creality Print
Printing speed:80-100mm/s
Files Format:STL/OBJ/AMF/3DMF
Product Features
Why choose FGF pellet 3D printer?New experience of industrial pellet 3D printing
  • More cost-effective
    Material cost, time cost and labor cost
    are all lower
  • Faster printing speed
    New-generation nozzle printing components
    optional 0.4-3.0 nozzle
  • Better material properties
    Direct use of original material
    all material properties intact
  • More environmentally friendly
    3D printable with pellets and shredded recycled plastic

Printing filament:PLA / PETG / PETG+10%GF / ABS / PA6 / PS / GPPS / PP /PP+30%GF / TPE / TPV / TPU/ 15-5PH PA-CF, PC-CF, PA-GF, ABS-CF, PLA-CF, ASA, and other composite materials.

Introduction to the printing processMulti-pellet printing
FGF pellet 3D printer applicationMulti-material, high-speed, low-cost, including R&D and production of printing materials and 3D intelligent equipment of the whole industry chain, serving the world.
Application
  • Application of mold 3D printer in mold manufacturing industry | Piocreat
    In today's modern society with the continuous development of science and technology, no matter which industry's products, the demand for molds is highly dependent. Many parts in most products need to be manufactured by molding (injection, blow molding and silica gel) or casting (investment molding, sanding and spinning). Therefore, no matter what industry or application, manufacturing molds can not only improve efficiency and profit, but also ensure the quality of products.In the past, CNC machining was the mainstream technology for manufacturing molds. Although the manufactured molds can provide reliable and effective results, the practical application of this technology is very time-consuming and expensive, so many products also increase a lot of costs. Therefore, many mold manufacturing enterprises are looking for more effective, time-saving and cost-saving methods to replace CNC technology.At present, the most suitable method for mold manufacturing is additive manufacturing (i.e....
  • Application of pellet 3D printer in furniture industry
    In the traditional design methods, the prototype design takes a long time, such as design, cutting, spraying, testing and so on. These methods need skilled craftsmen to do, which is an expensive cost and the waste of materials is inevitable. With the help of 3D printing technology, designers can design more complex models and greatly reduce the waste of materials. With the popularity of 3D printers, I can closely link design and production. For example, in the design process, the scale model data generated by household 3D printer can be directly used for the physical manufacturing of 3D printing factory to realize the perfect consistency between design and physical production. Today, FDM can be said to be the lowest budget 3D printing technology, but the cost of FGF made of particles is lower. For FGF technology, the filling and contour layered pattern hidden under the surface are the most representative features, but it is considered to be a rough defect.The three products on disp...
  • Application of pellet 3D printer in furniture making
    There are more and more demands for personalization and customization in the furniture industry, and such demands are generally more complex and urgent. If traditional craftsmanship is used, the production cost will be high and the time-consuming will be longer. However, the application of 3D printing technology makes up for these shortcomings, which can simplify the process of furniture processing wood, shorten the production cycle of furniture, reduce a lot of processing time, save labor and material costs, and save environmental protection and materials. Today we use the large-scale pellet 3D printer G12 of Piocreat3D to make this art chair. The maximum size of the chair is 80cm, and the printing size of G12 is 1.2*1*1 meter, which can meet the printing needs, and at the same time, in order to meet the hardness and strength requirements of the chair , we chose PETG and glass fiber consumables with small deformation for printing. Next we get to work.First, we need to import the d...
  • Application of 3D printing in kitchen and bathroom industry
    With the changes of the times, the real estate industry has experienced a period of vigorous development, and the house type standards and requirements of the market for commercial housing are becoming higher and higher. The kitchen and bathroom are the two spaces with the most problems, the most complex technology and the most difficult implementation. As the bearing space of kitchen and bathroom products - the product design of kitchen and bathroom directly affects the change of house type structure.As an innovative technology, 3D printing technology has been widely used in many industries and has made new breakthroughs in the kitchen and bathroom industry. The emergence of 3D printing faucet, 3D printing toilet, 3D printing shower, cabinet and other products marks that enterprises taking the lead in using this technology will take the lead in the product market, break the bottleneck of R & D and production time, catalyze the product iteration cycle and accelerate the speed of n...
