CR-Scan Otter

3D Body Scanner

The CR-Scan Otter is a portable handheld 3D body scanner featuring next-generation four-eye infrared structured light technology. It captures highly accurate human body data models, enabling precise alignment with X-ray images and ensuring a better fit for customized orthopedic braces. Ideal for medical and orthotic applications.

Features

Specs

Various Size Options

Innovative Four-lens Stereo Vision. Proficient in handling both large and small scans.

Capture SMALL & BIG Objects

Realizes the possibilities of scanning various objects, ranging in size from 10x10x10 mm to 2000x2000x2000 mm.

Ultra-High Precision

The scanning precision up to 0.02mm ensures every detail is sharp and clear.

Full-Color Scanning

Equipped with a million-pixel full-color RGB camera and an exclusive color mapping algorithm.

Cross-platform Compatibility

Cross-platform (Windows, macOS) operation, easy to use.

Elevate Scanning Experience

It allows for real-time exposure adjustment and offers comfortable and simple operation.

CR-Scan Otter Parameters
Accuracy	Up to 0.02mm@60mm
3D Resolution	0.05-2mm
Scanning Speed	Up to 20fps
Min. Scan Volume	10mm x 10mm x 10mm
Single Capture Range	Max. 1350x840mm@1000mm
Technology	Infrared structured light
Working Distance	110mm-1000mm
Color Mapping	YES
Alignment Modes	Geometry/Marker/Texture
Output Format	OBJ/STL/PLY
IMU	YES
Color Supplemental Light	2 white LEDS
Marker Recognition Enhancement	8 infrared LEDs
Laser Safety	Class I (eye safe)
System Support	Windows/macOS
Wireless Scanning	Supported
